Home Lifts. No Pit. No Machine Room.
A residential elevator for villas, duplexes and homes that are already built, on the same single-phase supply as the rest of your home.
- Series
- SL
- Pit depth
- 150 mm
- Capacity
- Up to 4 persons
- Stops
- Up to 4
Fitting an Existing Home
Will a Home Elevator Fit My Home?
Most people asking about a home lift are asking about a home that already exists. Floors are laid, walls are up, and the thought of excavating a pit or adding a structure on the terrace is what stops the conversation. The SL Series was designed around that problem.
150 mm Pit
A conventional lift wants a pit about a metre deep. This one works with 150 mm, which in most homes means no excavation at all. A pitless configuration is available where even that is not possible.
No Machine Room
The gearless machine sits inside the shaft itself. No machine room, no headroom structure on the terrace, nothing that changes the outline of your home from the street.
Single-Phase Power
230 V single-phase, the same supply as your air conditioner. No three-phase sanction, no transformer, no waiting on the DISCOM. Three-phase works too if you already have it.
Indoors or Outdoors
Inside the stairwell void, in a corner of the hall, or outside on an MS structure against a rear wall. Where there is no shaft, we build one in steel and glass rather than concrete.
Configuration Options
Which Home Lift Configuration Fits?
People rarely ask for a model. They ask for a lift for three floors, or a two-person lift for the home. Here it is in those terms.
2 & 3 Person Cabin
Fits the stairwell void you already have
The smallest sensible cabins, and what most villas and duplexes choose. A 3-person cabin gives enough room for a person with a walker, or a grandparent travelling with a child.
- Capacity
- 150 to 204 kg
- Stops
- 2 to 4
- Pit
- 150 mm
Suits
- G+1 and G+2 homes where the stairwell void is free
- Finished homes with no room for a new concrete shaft
- Households buying for an ageing parent
- Homes on single-phase supply only
4 Person Cabin
Comfortable for a family, and for a wheelchair
The largest cabin in the SL Series, and the usual choice where one resident uses a wheelchair or where the lift will carry more than two people at a time.
- Capacity
- 272 kg
- Stops
- Up to 4
- Speed
- 0.5 m/s
Suits
- G+2 and G+3 homes
- Wheelchair access between floors
- Larger villas with an outdoor MS and glass shaft
- Homes where the lift is a daily family route, not a backup
More than three floors above ground?
The SL Series stops at four stops. Beyond that we would fit the VL Series: still gearless, still machine-room-less. We would rather tell you that now than at the survey.
What It Costs
What Does a Home Lift Cost?
There is no single number, and anyone quoting one on a web page will revise it after the survey. But there is no reason to keep you in the dark either. Six things decide what you pay.
Number of Stops
G+1 costs less than G+3. Each stop adds a landing door, a guide rail run and wiring.
Capacity
2, 3 or 4 persons. A 272 kg cabin needs a larger shaft than a 2-person one, so the structure grows with it.
The Shaft
Using your existing stairwell void is the cheapest route. An MS structure with glass, built outside, costs more.
Doors
MS panel doors are the economical option. Automatic glass doors cost more and change how the lift reads from the landing.
Cabin Finish
Painted MS at the base, stainless steel above it, glass and custom lighting at the top of the range.
Running Cost
Roughly 30% less power than a conventional traction system, on single-phase supply. A small addition to the monthly bill, not a new one.
The honest version
For most independent homes in Hyderabad and Bangalore, a 2 to 3 person SL Series serving two or three floors sits in a predictable band. We will tell you that band on the phone in five minutes, before anyone visits.
Is hydraulic cheaper?
Hydraulic home lifts work, but need an oil tank and pump housed near the shaft and give a slower ride. The SL Series is gearless traction with the machine inside the shaft: quieter, no oil to change, and nothing to house outside. If hydraulic genuinely suits your site better, we will say so at the survey.
Technical Detail
SL Series Home Elevator Specifications
Gearless traction and machine-room-less: a residential elevator built for home duty rather than adapted from a commercial lift.
Drive & Speed
Gearless traction, machine-room-less (MRL). 0.5 m/s. Microprocessor controller with VVVF drive.
Capacity & Stops
Up to 4 persons or 272 kg, serving up to 4 stops. Steel wire rope suspension.
Site Requirements
150 mm pit minimum, pitless option available. 2800 mm overhead. 230 V single-phase or 415 V three-phase, 50 Hz.
Doors & Structure
Automatic glass doors standard, MS doors optional. MS structure available for outdoor installation. ISO 9001:2015.
Engineered Protection
Built for the People You Are Installing It For
Most home lifts get bought for a specific person: a parent who has stopped using the stairs, someone recovering from surgery, a grandchild too small to manage three floors. The systems below are standard, not optional extras.
A power cut should not be an emergency
When the supply drops, the Automatic Rescue Device moves the cabin to the nearest floor under its own battery power and opens the doors. Nobody sits inside waiting for the generator to pick up.
It is the question every family asks before they sign, and on the SL Series it is answered in the standard specification rather than as a priced add-on.
Where They Are Installed
Homes the SL Series Was Built For
Villas
Glass cabin in the central stairwell, where the lift is part of the entrance rather than hidden behind a door.
Duplexes
Two or three stops, compact cabin, usually fitted into the void the staircase already wraps around.
Existing Independent Homes
Finished homes with no pit and no terrace structure. The 150 mm pit is what makes these possible at all.
Homes With No Internal Shaft
An MS and glass structure against a rear or side wall, built outside and tied into each floor.
Site Survey
Every Home Is Different
From first call to first ride
No part of this needs you to know anything about elevators. Tell us the floors and the number of people, and the survey settles the rest.
You Call or Send Photos
Photos of the stairwell, or the wall where you want it, are enough to start.
Free Site Survey
An engineer measures the shaft, the floor level below and your power supply, and confirms what fits.
Quotation & Finishes
One written quotation with capacity, stops, doors and cabin finish spelled out. You choose finishes now, not after.
Free survey. No obligation.
Book Free Site SurveyWorking With Us
Why Choose Sneha Elev8r?
Manufactured in Hyderabad
Parts come from the same city. A spare is a drive away rather than a shipment, and there is no importer's margin in the price.
We Service What We Install
Our own engineers across Telangana, Andhra Pradesh and Karnataka. Not a franchisee, and not a ticket raised to another state.
Residential Specification
The SL Series is built for home duty, not a commercial lift with a smaller cabin bolted on.
ISO 9001:2015
Quality systems certified, with safety features supplied as standard rather than priced as extras.
Straight Answers on Fit
If your home needs a different series, or hydraulic suits your site better, we say so at the survey instead of after the order.
Short Site Work
No pit to dig and no machine room to build, which is what keeps disruption in a finished home down to days.
Common Questions
Frequently Asked Questions
Still unsure? A free site survey settles most of this in one visit.
Book Free Site SurveyIt depends on four things: how many floors it serves, how many people it carries, whether it goes into your existing stairwell or needs an outdoor structure, and the door and cabin finish you choose. A 2-person lift serving two floors in an existing stairwell is the most economical configuration. Tell us your floors and persons and we will give you a realistic range on the phone before anyone visits.
Less than most people expect. The SL Series needs 150 mm below floor level and 2800 mm of overhead, with no pit excavation and no machine room. In most independent homes the existing stairwell void is enough. Where it is not, we build a steel and glass shaft outside against a wall.
Yes, and that is what the SL Series was designed for. Because the machine sits inside the shaft and the pit is 150 mm, there is usually no structural work: no digging, no new concrete shaft, no machine room on the terrace.
No. It runs on 230 V single-phase, the same supply that powers your air conditioner. Three-phase works too if you already have it.
Up to 4 stops, so G+3, and up to 4 persons or 272 kg. Two- and three-person cabins are available and are what most independent homes choose. For more than four stops we would recommend the VL Series.
Both work. Hydraulic needs an oil tank and pump housed near the shaft and gives a slower ride. The SL Series is gearless traction with the machine inside the shaft: quieter, no oil, around 30% less power, and nothing to house outside the shaft. At the survey we will say plainly if hydraulic suits your site better.
The Automatic Rescue Device brings the lift to the nearest floor and opens the doors on its own. It is standard, not an add-on.
Yes. We build an MS structure against an external wall, usually with glass, where there is no internal shaft available.
Yes. We manufacture in Hyderabad and run our own service across Telangana, Andhra Pradesh and Karnataka. The AMC schedule is handed over at commissioning.
Book a Free Site Survey
Find Out What Fits Your Home
Free survey, no obligation, same-day callback
Tell us the number of floors and how many people the lift needs to carry. We will tell you what fits and roughly what it costs before an engineer visits.
Request your site survey
Our engineering team will call you back the same working day.
